HZ-2607 Metal ESD Magazine Rack 460*400*563

+862131131775

Categories

HZ-2607 Metal ESD Magazine Rack 460*400*563
item No : HZ-2607
Contour Size(L×W×H)mm: 460*400*563 ; 80 ℃，120℃ and 200 ℃ are available;Production time: In stock; Package: 50sets / pallet;
Inquiry now

HZ-2607 Metal ESD Magazine Rack 460*400*563

Material: Conductive PP /PPE, Zinc Coating Steel, Aluminium Alloy

Application:

-Store and logistic PCB, Electronic components

-ESD Protection on SMT, SMD , Semiconductor industrial

-Accoding to ANSI/ESD S20.20 Standard, ISO9001:2008 quality system .

Description	HZ-2607
Contour Size	(L×W×H)mm: 460400563
Storage slot	50pcs of Plates can be stored
The specification of PCB plates	460*(50－330)mm
Guide slot of side plate	Depth 4mm, Width 5.5mm, Pitch 10mm
Material	Top and bottom Base are metal base
Fix method	Screw or gear track adjustable
Side plate	Five pieces assembled
Weight	8.0KG
Surface Resistance	10³－10⁹Ω
Temperature	80 ℃,120℃ and 200 ℃ are available.
Aluminum alloy material side plate is available

HZ-2607 Metal ESD Magazine Rack 460400563
